Water Heater Installation in San Diego


When a water heater has to be replaced, the tank itself is the simple part. What separates a good job from a bad one is everything around it. That means the right size for the household, the earthquake straps, the relief valve drain, the expansion tank, the gas and vent connections, and the permit. Courtesy Plumbing does water heater installation in San Diego on weekdays from 8 AM to 5 PM, for both gas and electric tank heaters. Here is how to size the new heater and what a complete, code-correct replacement includes.

Not sure the old heater is finished? Many problems are a single part. Our water heater repair page helps you tell a repair from a replacement.

Sizing: Read the First Hour Rating, Not Only the Gallons

Most people replace a 40-gallon tank with another 40-gallon tank. That works if the household hasn’t changed. If it has, the number to look at is the first hour rating. The U.S. Department of Energy defines it as the gallons of hot water a heater can supply in one hour, starting with a full tank. It’s printed on the yellow EnergyGuide label, in the top left corner.

To use it, add up your busiest hour. The Department of Energy’s worksheet counts about 20 gallons for a shower, 7 for a dishwasher cycle and 25 for a top-loading clothes washer. Its example household takes three showers, one shave and one round of hand dishwashing in its peak hour, for 66 gallons. That home needs a heater with a first hour rating of 66 or more. The full worksheet takes five minutes.

Two tanks with the same gallon size can have different first hour ratings, because burner or element size matters as much as the tank. That’s why we ask how many people live in the house, and when they shower, before we recommend a model.

What a Code-Correct Replacement Includes

Codes change over the life of a heater, so a replacement almost never goes back exactly as the old one was. We often find an old heater with no drain pan and no expansion tank at all. On every install we check these items and bring them up to current code:

Item

What California code calls for

What it prevents

Earthquake straps

Two straps, one in the upper third of the tank and one in the lower third. The lower strap sits at least 4 inches above the controls.

A tank that tips in an earthquake can tear its gas and water lines.

Relief valve drain line

Full size, running downhill by gravity, pointing down at the end, with no valve or cap anywhere on it.

Lets the valve release safely if temperature or pressure climbs too high.

Expansion tank

Required when the house has a pressure regulator, check valve or other device that keeps water from pushing back into the main.

Heated water expands. With nowhere to go, pressure spikes on every heating cycle.

Drain pan

A watertight pan with a drain line at least 3/4 inch, wherever a leaking heater would cause damage, such as an attic, an upper floor or an interior closet.

Catches a slow leak and sends it somewhere you will see it.

Garage height

Burners and igniters at least 18 inches above the garage floor, unless the heater is a listed flammable vapor ignition resistant model.

Keeps ignition sources away from fuel vapors near the floor.

On gas heaters we also fit a new gas connector, test every joint for leaks, and check that the vent draws properly before we leave. On electric heaters we check that the existing circuit matches the new unit’s rating.

The City Permit

Inside the City of San Diego, replacing a tank water heater falls under the Simple No-Plan plumbing permit. The City’s fee schedule listed the water heater permit at $122.97 as of May 2026. An inspector visits after the install and looks at the same items in the table above. We pull the permit and book the inspection. Tankless heaters aren’t covered by that simple permit and go through a different one.

If a quote for a water heater swap doesn’t mention a permit, ask about it. The inspection is the only independent check on the gas, venting and strapping you’ll get.

How Installation Day Goes

  1. Shut down and drain. Gas or power off, water off, and the old tank drained through a hose to a safe spot.
  2. Remove the old heater. We disconnect it, carry it out and haul it away.
  3. Set the new one. The new heater goes in level, on its pan or stand where one is required, and gets strapped.
  4. Reconnect. Water lines, shutoff valve, relief valve drain, expansion tank, gas or electric, and vent.
  5. Fill and fire. The tank is filled and air is purged from the hot lines before the burner or elements come on.
  6. Walk through. We show you the shutoffs, the temperature setting and what maintenance the heater needs.

Most straightforward swaps take a few hours. On one job, a heater about 15 years old came out and its replacement was running in roughly two and a half hours. That included a better shutoff valve, a new pan and an expansion tank. Another went in about an hour because the owner had already drained the old tank before we arrived.

Condos and tight closets take more care, but not always more time. In one condo the old heater was leaking onto the floor. Our plumber had the new one in about two and a half hours after he arrived, then walked the owner through its maintenance.

A failed heater rarely picks a good day. One customer’s 13-year-old tank died right before a weekend and left water in the garage. Our plumber drained it and hauled it off, picked up the right replacement, fitted a new connector pipe where one was needed, purged the air and cleaned up.

Tank, Tankless or Heat Pump?

A like-for-like tank is the fastest and least expensive replacement, because the gas, vent and water connections are already in the right place. The other two types can cost less to run. They also change the installation:

  • Tankless heats water as you use it, so there’s no tank to empty, but it often needs a larger gas line and new venting. See our tankless water heater installation page.
  • Heat pump water heaters run on electricity and need space, airflow and a place for condensate to drain. Our heat pump water heater installation page lists what the location needs.

If you want the three compared side by side, our La Mesa water heater guide does that.

What to Have Ready When You Call

  • A photo of the label on the old heater, which shows the gallons, the fuel type and the age.
  • Where the heater sits: garage, outdoor closet, indoor closet, attic or upstairs.
  • How many people live in the house and when the busy hour is.
  • Anything that has changed, such as a new bathroom or a bigger tub.

With that, we can often give you a price by phone. Call (858) 567-0544 between 8 AM and 5 PM on a weekday, or send the label photo through our Contact Us form. Our California contractor license is CSLB #910268, and the company has belonged to its founder, master plumber Tony Misleh, since 2007.
